REMARKS
The
steel inserted frame is diecasted with aluminum
alloy to maintain dynamic and thrust power.
The top plate is dieforged and
machined precisely and wheel is injected with
engineering plastic nylon which has better
properties of impact, compressive strength and
wearlessness. The leveling pad of
N.B.R. is normal and Urethane is arranged by order
APPLICATIONS
Test, medical, optical, clean room equipments;
Frame of light weight computers, Control panels,
Semiconductor equipments, Switchboards, F.M.S.
line, etc. |
Specifications |
|
| LOAD
CAPACITY
|
| ANALYSIS |
lbs |
| Load
per Piece |
1,650 |
| Recommended
Load per 4 pieces |
3,300 |
| Net
Weight |
GD-100F |
4.62 |
| GD-100S |
3.96 |
| Temperature
Range |
-14 ~ 250oF |
|
MATERIALS
| No |
Parts |
Materials |
Remarks |
| 1* |
Top Plate |
1045 |
Zn galvanized |
| 2* |
Ball |
1045 |
Ni-Cr. galvanized |
| 3 |
Frame |
SC114A |
Ivory powder coated |
| 4 |
Handle |
Nylon-6 |
Orange |
| 5* |
M-12 Leveler |
1045 |
Zn galvanized |
| 6 |
Pad |
N.B.R. |
Urethane by order |
| 7* |
Pin |
1045 |
Zn galvanized |
| 8 |
Wheel |
Nylon-6 |
Black |
| In
case of requiring of ANTI-CORROSION, parts of "*"
are issued with stainless steel or speecial
surface treatment by order. |
